Super Fast Recovery Rectifier
Super Fast Recovery Rectifier
Super Fast Recovery Rectifiers are designed for high-frequency power-conversion circuits where reverse-recovery behavior has a significant influence on switching performance.
Fast reverse recovery helps reduce recovery-related switching losses and can assist engineers in controlling voltage spikes and EMI in appropriately designed circuits. Selection should consider not only reverse-recovery time (trr), but also reverse-recovery charge (Qrr), forward voltage, leakage current, current capability and operating temperature.
Super Fast Recovery Rectifier
Filter 262 products by Package, VRRM, IF, Configuration, IFSM_Max, VF_Max, Rated IF, Status, IR@125°C(uA), Tj, Trr_Max and IR@25°C(uA).
Fast Search
- Package
- VRRM(V)
- IF(A)
- VF_Max(V)
| Product Name | Package | VRRM(V) | IF(A) | Configuration | IFSM_Max(A) | VF_Max(V) | Rated IF(A) | Status | IR@125°C(uA) | Tj(°C) | Trr_Max(ns) | IR@25°C(uA) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| | VRRM(V) | IF(A) | | IFSM_Max(A) | VF_Max(V) | Rated IF(A) | | IR@125°C(uA) | Tj(°C) | Trr_Max(ns) | IR@25°C(uA) | |
| TO-220AC | 600 | 10 | Single Positive | 150 | 1.75 | 5 | Active | 300 | -55℃~+150℃ | 35 | 30 | |
| ITO-220AC | 600 | 10 | Single Positive | 120 | 1.75 | 5 | Active | 300 | -55℃~+150℃ | 35 | 30 | |
| TO-220AC | 600 | 15 | Single Positive | 200 | 2.2 | 7.5 | Active | 500 | -55℃~+150℃ | 35 | 50 | |
| ITO-220AB | 200 | 16 | Common Anode | 125 | 1.05 | 8 | Active | 250 | -55℃~+150℃ | 35 | 5 | |
| TO-220AB | 400 | 16 | Common Anode | 125 | 1.3 | 8 | Active | 500 | -55℃~+150℃ | 35 | 50 | |
| TO-220AB | 600 | 16 | Common Anode | 125 | 1.75 | 8 | Active | 500 | -55℃~+150℃ | 35 | 50 | |
| ITO-220AB | 600 | 16 | Common Anode | 125 | 1.75 | 8 | Active | 500 | -55℃~+150℃ | 35 | 50 | |
| TO-220AB | 400 | 20 | Common Anode | 150 | 1.3 | 10 | Active | 300 | -55℃~+150℃ | 35 | 30 | |
| TO-220AB | 600 | 20 | Common Anode | 150 | 1.75 | 10 | Active | 300 | -55℃~+150℃ | 35 | 30 | |
| ITO-220AB | 600 | 20 | Common Anode | 150 | 1.75 | 10 | Active | 300 | -55℃~+150℃ | 35 | 30 | |
| TO-263 | 200 | 30 | Common Anode | 200 | 1.1 | 15 | Active | 300 | -55℃~+150℃ | 35 | 30 | |
| TO-220AB | 400 | 30 | Common Anode | 200 | 1.35 | 15 | Active | 500 | -55℃~+150℃ | 35 | 50 |
Jump to
Show
per page
262
results
Featured Super Fast Recovery Rectifiers
COMMON INQUIRIES
SUPER FAST RECOVERY RECTIFIERS FAQ
Power Semiconductor Manufacturing Equipment
Manufacturing Capability
Professional Power Semiconductor Manufacturing Capability
Founded in 2009, POWERSi has focused on power semiconductors for more than a decade. We integrate product R&D, packaging and testing, sales, and technical support into one service system. With a manufacturing area exceeding 10,000 square meters, ISO9001:2015 certification, and ERP and MES management platforms, we strengthen production coordination, process management, and quality control.
POWERSi supplies rectifier bridges, rectifier diodes, Schottky diodes, fast-recovery rectifiers, thyristors, MOSFETs, and SiC devices for industrial, energy, and electronics-manufacturing customers. Supported by professional manufacturing capabilities and responsive technical support, we help customers move efficiently from product selection to sample evaluation and application matching.
Why Global Engineers Choose POWERSi
- 17 Utility Model Patents in Power Devices
- ISO9001:2015 Certified Manufacturing
- 10,000 m² Integrated Production Base
- 300+ Enterprise Customers Served Worldwide
