High Efficient Rectifier
High-Efficiency Rectifier
High-Efficient Rectifier are developed for power-conversion systems requiring a balanced combination of conduction loss, switching performance and thermal capability.
Compared with conventional rectification solutions, this product family is designed to help engineers optimize overall system efficiency while maintaining suitable voltage and current capability. Device selection can be made according to forward voltage, reverse-recovery characteristics, leakage current, operating frequency and thermal requirements.
High Efficient Rectifier
Filter 275 products by Package, VRRM, IF, Configuration, IFSM_Max, VF_Max, Rated IF, Status, IR@125°C(uA), Tj, Trr_Max and IR@25°C(uA).
Fast Search
- Package
- VRRM(V)
- IF(A)
- VF_Max(V)
| Product Name | Package | VRRM(V) | IF(A) | Configuration | IFSM_Max(A) | VF_Max(V) | Rated IF(A) | Status | IR@125°C(uA) | Tj(°C) | Trr_Max(ns) | IR@25°C(uA) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| | VRRM(V) | IF(A) | | IFSM_Max(A) | VF_Max(V) | Rated IF(A) | | IR@125°C(uA) | Tj(°C) | Trr_Max(ns) | IR@25°C(uA) | |
| DO-27/DO-201AD | 50 | 5 | Single Positive | 150 | 1 | 2.5 | Active | - | -65℃~+150℃ | 50 | 10 | |
| DO-27/DO-201AD | 100 | 5 | Single Positive | 150 | 1 | 2.5 | Active | - | -65℃~+150℃ | 50 | 10 | |
| DO-27/DO-201AD | 200 | 5 | Single Positive | 150 | 1 | 2.5 | Active | - | -65℃~+150℃ | 50 | 10 | |
| DO-27/DO-201AD | 300 | 5 | Single Positive | 150 | 1.3 | 2.5 | Active | - | -65℃~+150℃ | 50 | 10 | |
| DO-27/DO-201AD | 400 | 5 | Single Positive | 150 | 1.3 | 2.5 | Active | - | -65℃~+150℃ | 50 | 10 | |
| DO-27/DO-201AD | 600 | 5 | Single Positive | 150 | 1.7 | 2.5 | Active | - | -65℃~+150℃ | 75 | 10 | |
| DO-27/DO-201AD | 800 | 5 | Single Positive | 150 | 1.7 | 2.5 | Active | - | -65℃~+150℃ | 75 | 10 | |
| DO-27/DO-201AD | 1,000 | 5 | Single Positive | 150 | 1.7 | 2.5 | Active | - | -65℃~+150℃ | 75 | 10 | |
| ITO-220AB | 1,000 | 10 | Common Cathode | 125 | 1.7 | 2.5 | Active | 300 | -55℃~+150℃ | 75 | 5 | |
| TO-220AC | 600 | 16 | Single Positive | 250 | 1.7 | 8 | Active | 300 | -55℃~+150℃ | 50 | 30 | |
| ITO-220AC | 600 | 16 | Single Positive | 250 | 1.7 | 8 | Active | 300 | -55℃~+150℃ | 50 | 30 | |
| TO-220AB | 1,000 | 20 | Common Anode | 150 | 2.3 | 10 | Active | 300 | -55℃~+150℃ | 75 | 30 |
Jump to
Show
per page
275
results
Featured High-Efficiency Rectifiers
-
MUR3040CA 30A 400V 50ns Common-Anode Fast Recovery Rectifier
-
MUR3040CL 30A 400V K-AK-A Fast-Recovery Rectifier
-
MUR3040CR 30A 400V A-KA-K Low VF High Efficiency Rectifier
-
MUR3040CT 30A 400V 200A Surge Common-Cathode Fast Recovery Rectifier
-
MUR3060PA 30A 600V Low-Leakage Common-Anode Fast Recovery Rectifier
-
MUR3060PT 30A 600V 50ns Common-Cathode Fast Recovery Rectifier
COMMON INQUIRIES
HIGH-EFFICIENCY RECTIFIERS FAQ
Power Semiconductor Manufacturing Equipment
Manufacturing Capability
Professional Power Semiconductor Manufacturing Capability
Founded in 2009, POWERSi has focused on power semiconductors for more than a decade. We integrate product R&D, packaging and testing, sales, and technical support into one service system. With a manufacturing area exceeding 10,000 square meters, ISO9001:2015 certification, and ERP and MES management platforms, we strengthen production coordination, process management, and quality control.
POWERSi supplies rectifier bridges, rectifier diodes, Schottky diodes, fast-recovery rectifiers, thyristors, MOSFETs, and SiC devices for industrial, energy, and electronics-manufacturing customers. Supported by professional manufacturing capabilities and responsive technical support, we help customers move efficiently from product selection to sample evaluation and application matching.
Why Global Engineers Choose POWERSi
- 17 Utility Model Patents in Power Devices
- ISO9001:2015 Certified Manufacturing
- 10,000 m² Integrated Production Base
- 300+ Enterprise Customers Served Worldwide
